Spray Cleaning Equipment for Brass Valves with Rotating Spray Arms Drying Plumbing Industry
Rotating spray arms deliver 160bar pressure to clean brass valves thoroughly. The compact design fits small workshops, and the 55℃ dryer preserves brass luster. Removes machining oil and polishing compounds, ideal for plumbing valve factories, ensuring tight sealing performance.
Cleaning requirements (residues):
| 1. Total weight less than or equal to 4.5mg |
| 2. Metal diameter less than or equal to 600um |
| 3. Non-metallic diameter less than or equal to 1800um |
| 4. Fiber length is less than or equal to 4000um |
| 5. After cleaning, there should be no watermark on the surface (with pure water machine), and it should be completely dry (blind hole) |
Reference of process flow:(workpiece flow direction → left in and right out)
Manual feeding → ultrasonic cleaning → fixed-point spraying → air cutting → fixed-point spraying → mobile spraying → mobile air cutting → fixed-point air cutting → vacuum drying → cooling section → automatic unloading (truss manipulator) → full inspection and packaging
Partial configuration Of Spray Cleaning Equipment:
2.1 Feeding section (feeding section of cleaning machine):
| ordinal | 1 section (section 1); 1 work station |
| structure | configure | Working width: 900±20mm (production drawing is subject to); working table height 1000±20mm. Reducer motor control; Yongkun brand; Mechanical safety protection of motor chain (the installation position of the motor is opposite to the operation face); Transportation mode: step-by-step transportation; Set a counting sensor and three sets of stop, start and conveyance pause buttons; |
For a complete technical solution Of Spray Cleaning Equipment, please contact me. We will customize the design based on your product technical requirements and factory layout.
